NVIDIA GTX 590 Database - Specs, information & files

NVIDIA GTX 590

Specs, info and data

The GPU Database

Featuring 310+ GPU models — and growing.

Database > GPUs > NVIDIA GTX 590

NVIDIA GTX 590

The GTX 590 is a consumer-grade GPU from nvidia's GeForce 500 series, built on the Fermi 2.0 architecture using the GF110 chip. Equipped with 1.5 GB of GDDR5 memory on a 384-bit bus, it delivers 164.0 GB/s of bandwidth at 3.4 Gbps.

Launched on 23 Mar, 2011, the GTX 590 carried a starting price of $699.

GPUs.net

Information
PlatformConsumer
ArchitectureFermi 2.0
GenerationGeForce 500
Previous GenGeForce 400
Next GenGeForce 600
InterfacePCIe 2.0 x16
Core
NameGF110
FoundryTSMC
Process Node40 nm
Transistors3000 million
Die Size520.0 mm²
Density5.8 /mm²
GPU Core Config
Cores512
TMUs64
ROPs48
SMs16
Memory
TechnologyGDDR5
Size1.5 GB
Bus384 bit
Bandwidth164.0 GB/s
Speed3.4 Gbps

Information
Platform	Consumer
Architecture	Fermi 2.0
Generation	GeForce 500
Previous Gen	GeForce 400
Next Gen	GeForce 600
Interface	PCIe 2.0 x16

Core
Name	GF110
Foundry	TSMC
Process Node	40 nm
Transistors	3000 million
Die Size	520.0 mm²
Density	5.8 /mm²

GPU Core Config
Cores	512
TMUs	64
ROPs	48
SMs	16

Memory
Technology	GDDR5
Size	1.5 GB
Bus	384 bit
Bandwidth	164.0 GB/s
Speed	3.4 Gbps

Clocks
Base clock608 MHz
Shader Clock1215 MHz
Memory Clock854 MHz
Power
8-pin2
TDP365 w
Recommended PSU700 w
Display
Mini DisplayPort1
DVI3
Dimensions
Slots2
Length279 mm
Height111 mm
Width40 mm

Clocks
Base clock	608 MHz
Shader Clock	1215 MHz
Memory Clock	854 MHz

Power
8-pin	2
TDP	365 w
Recommended PSU	700 w

Display
Mini DisplayPort	1
DVI	3

Dimensions
Slots	2
Length	279 mm
Height	111 mm
Width	40 mm

Models

GPU▲	Shader Clock▲	Slots▲	Length▲	Height▲	Width▲
MSI GeForce GTX 590 N590GTX-P3D3GD5	-100.0%	2	280 mm	111 mm	38 mm
