NVIDIA RTX 4000 Ada

The RTX 4000 Ada is a workstation-grade GPU from nvidia's GeForce RTX 40 series, built on the  architecture using the AD104 chip. Equipped with 20 GB of GDDR6 memory on a 160-bit bus, it delivers 360.0 GB/s of bandwidth at 18.0 Gbps.

Launched on 8 Aug, 2023, the RTX 4000 Ada carried a starting price of $1999.

FP16 Tensor Benchmark76.72 TFLOPS 71.8%
 Theoretical106.9 TFLOPS
FP32 Benchmark31.72 TFLOPS 118.7%
 Theoretical26.7 TFLOPS
FP65 Benchmark0.36 TFLOPS 86.2%
 Theoretical0.42 TFLOPS
Host RTX 4000 Ada
Earn $0.09/h*
Vast
* Median price
Mine with RTX 4000 Ada
Earn $0.05/d*
Estimates
* Before power cost

Information
PlatformWorkstation
ArchitectureAda Lovelace
GenerationGeForce RTX 40
Previous GenGeForce RTX 30
Next GenGeForce RTX 50
InterfacePCIe 4.0 x16
Core
NameAD104
FoundryTSMC
Process Node5 nm
Transistors35800 million
Die Size294 mm²
Density121.8 /mm²
GPU Core Config
Cores6144
TMUs192
ROPs64
SMs48
Tensor Cores192
RT Cores48
Memory
TechnologyGDDR6
Size20 GB
Bus160 bit
Bandwidth360 GB/s
Speed18 Gbps

Information
Platform	Workstation
Architecture	Ada Lovelace
Generation	GeForce RTX 40
Previous Gen	GeForce RTX 30
Next Gen	GeForce RTX 50
Interface	PCIe 4.0 x16

Core
Name	AD104
Foundry	TSMC
Process Node	5 nm
Transistors	35800 million
Die Size	294 mm²
Density	121.8 /mm²

GPU Core Config
Cores	6144
TMUs	192
ROPs	64
SMs	48
Tensor Cores	192
RT Cores	48

Memory
Technology	GDDR6
Size	20 GB
Bus	160 bit
Bandwidth	360 GB/s
Speed	18 Gbps

Clocks
Base clock1500 MHz
Boost Clock2175 MHz
Memory Clock2250 MHz
Power
8-pin1
16-pin1
TDP130 w
Recommended PSU300 w
Display
DisplayPort4
Dimensions
Slots1
Length245 mm
Height112 mm
Width20 mm

Clocks
Base clock	1500 MHz
Boost Clock	2175 MHz
Memory Clock	2250 MHz

Power
8-pin	1
16-pin	1
TDP	130 w
Recommended PSU	300 w

Display
DisplayPort	4

Dimensions
Slots	1
Length	245 mm
Height	112 mm
Width	20 mm

Models

GPU▲	Boost Clock▲	Slots▲	Length▲	Height▲	Width▲
