| Platform | Consumer |
| Architecture | Ampere |
| Generation | GeForce RTX 30 |
| Interface | PCIe 4.0 x16 |
| Max temperature | 93 C |
| Name | GA102 |
| Foundry | Samsung |
| Process Node | 8 nm |
| Transistors | 28300 million |
| Die Size | 628 mm² |
| Density | 45.1 /mm² |
| Cores | 10496 |
| TMUs | 328 |
| ROPs | 112 |
| Tensor Cores | 328 |
| RT Cores | 82 |
| Technology | GDDR6X |
| Size | 24 GB |
| Bus | 384 bit |
| Bandwidth | 936.192 GB/s |
| Speed | 19.504 Gbps |
| Base clock | 1395 MHz |
| Boost Clock | 1695 MHz |
| Memory Clock | 1219 MHz |
| TDP | 350 w |
| Recommended PSU | 750 w |
| DisplayPort | 3 |
| HDMI | 1 |
| Resolution | 7680x4320 |
| Monitors | 4 |
