| Platform | Workstation |
| Architecture | Blackwell 2nd-gen |
| Generation | Blackwell PRO W |
| Interface | PCIe 5.0 x16 |
| Name | GB202 |
| Foundry | TSMC |
| Process Node | 5 nm |
| Transistors | 92200 million |
| Die Size | 750 mm² |
| Density | 122.9 /mm² |
| Cores | 24064 |
| TMUs | 752 |
| ROPs | 192 |
| Tensor Cores | 752 |
| RT Cores | 188 |
| Technology | GDDR7 |
| Size | 96 GB |
| Bus | 512 bit |
| Bandwidth | 1792 GB/s |
| Speed | 28 Gbps |
| Base clock | 1590 MHz |
| Boost Clock | 2280 MHz |
| Memory Clock | 1750 MHz |
| 16-pin | 1 |
| TDP | 300 w |
| Recommended PSU | 700 w |
| DisplayPort | 4 |
| Slots | 2 |
| Length | 267 mm |
| Height | 112 mm |
